MT-s905 is a quad core HEVC 4K@60fps androidss OTT/IPTV set-top box.It is designed for ISPs,OTT
Operators and content aggregators that provide services based on IPTV,OTT and VoD.
ARM Cortex-A53 quad Core CPU,androidss 5.1
4K@30fps HEVC Main-10 Decoding
DRM:Widevine,Playready,Verimatrix,Marlin
Support PPPoE、DHCP、LAN Multiple access methods.
Support IPV4/IPV6
Support IEEE 802.11b/g/n
Support Bluetooth 4.0
Support 10/100Mbps Ethernet RJ45 port
Support 2*USB port
Support 1* CVBS
Support 1*SPDIF
Support one Micro SD card interface
Product specification | ||
Processor | CPU | ARM Cortex-A53 quad Core CPU |
GPU |
Penta-core ARM Mali-450 GPU up to 750MHz+(DVFS) Dual Geometry processors and triple pixel processors | |
System | UI | androidss |
OS | androidss 5.1 | |
Memory | DRAM | 2GB,DDR3 |
Flash | 8GB,eMMC | |
Interface | Power | 12V,1A |
USB | USB2.0 x2,support mouse&keyboard | |
Ethernet | RJ45 | |
HDMI | HDMI2.0,video output | |
SPDIF | Fiber audio output | |
SD Card | TF Card | |
MINI AV | 1 to 3 (3.5mm) | |
Network | Wi-Fi | Wi-Fi 2.4GHz 300M IEEE 802.11b/g/n |
bluetooth | Bluetooth 4.0 | |
IR | Internal IR receiver | |
Ethernet | RJ45 Interface 10M/100M IEEE 802.3u | |
video | Format | AVI,FLV,ISO,M2TS,MKV,MOV,MP4,MPG,MPEG,RM,RMVB,TS,VOB,WMV,DAT,3GP,DIVX,F4V,ASF,M2V etc. |
Decoder | H.265 4K*2K@60fps,H.264 4K*2K@30fps,AVS+,MPEG1/2/4 ASP,WMV/VC-1,Realmedia8/9/10 | |
Max resolution | 1080P | |
audio | Format | MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc. |
Decoder |
MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro, FLAC, OGG etc. Support dobby(optional)&DTS(optional) | |
Photo | Format | GIF,JPG,JPEG,BMP,PNG etc. |
Power Consumption | Consumption | 8W Max |
Environment |
Operation temperature | 0~40℃ |
Humidity | 5~95(%RH) | |
Accessory list | Accessory | 4K IPTV BOX |
Remote control | ||
battery | ||
Power adapter | ||
HDMI cable | ||
User manual | ||
Size | 110*110*21.5mm | |
Material | Plastic | |
Color | Black,White, | |
Accessory list | Accessory | 4K IPTV BOX |
Remote control | ||
battery | ||
Power adapter | ||
HDMI cable | ||
MINI AV cable | ||
User manual |
